White Rodgers WR586 Style Reversing Contactor 24V, 36V & 48V

Description

White Rodgers WR586 Style Reversing Contactor 12V, 24V, 36V & 48V

• 586 Style SPDT
• 24, 36 & 48 Volt Coils
• Water resistant
• Double-make or double-break contacts
  Capable of handling high and low current
• Rated load: making & breaking 200 Amps
• Inrush Current: 600 Amps
• Temperature Range: -40℉ to 150℉
• Terminations
  • Contacts: 5/16″-24 UNF-2A thread
  • Coil: #10-32 UNF-2A thread
• Recommended Mounting
  • Vertical plane with coil terminals up
• Hardware Torque Specification
  • Contact Terminal: 60 inch-lbs., max
  • Coil Terminal: 12-18 inch lbs.
  • Water Resistant

It takes two of these contactors to reverse a Series or PM motor.
See diagram here.
